Brand
Link®
Shield type
Served (Approx. 36/0.12A)
Capacitance at 1kHz, 20°C (Partial C. Value)
115pF/m(35pF/Ft)
Inductance between conductors at 1kHz. 20°C
0.3µH/m(0.092µH/Ft)
Voltage Breakdown
Must withstand at DC 500V/15sec.
Insulation Material
LNXLPE (Low Noise Cross – Linked polyethylene) and Flexible PVC
Insulation Resistance
100000 MΩ × m Min. at DC 125V, 20°C
Tensile Strength
284N
